1. Can the flow coefficient of a Venturi flowmeter be greater than 1?

It cannot be greater than 1. Because the flow coefficient of a Venturi flowmeter is equal to the ratio of the actual flow index of the liquid to the theoretical flow rate of the Venturi flowmeter, and the actual liquid has a cavity head loss in motion, the actual flow velocity is smaller than that of the Venturi flowmeter. Since Q=AV, Q

2. Venturi flowmeter experimental principle and calculation formula

Venturi flowmeter experimental principle and calculation formula Experimental principle: Venturi flowmeter is a flow measurement device designed based on the Venturi effect and the basic principles of fluid mechanics. The Venturi effect refers to the increase in fluid velocity when a restricted flow passes through a reduced cross-section, and the velocity is inversely proportional to the cross-section. In a Venturi tube, when fluid flows through the throttling element (i.e. the throat), local contraction occurs, resulting in an increase in flow velocity and a decrease in static pressure, thereby creating a pressure difference before and after the throat. There is a direct relationship between this pressure difference and fluid flow rate, so fluid flow rate can be calculated by measuring the pressure difference. Specifically, the working principle of the Venturi flowmeter is based on the continuity equation and Bernoulli equation of fluid flow. The Bernoulli equation describes the relationship between pressure, flow velocity, density, gravitational accelerat

1 and p2 are the pressure at points 1 and 2, v

1 and v2 are the flow velocity at points 1 and 2, ρ is the fluid density, g is the gravitational acceleration, and h

1 and h2 are the heights at points 1 and 2, respectively (which can be ignored in contour flow). Flow continuity equation: Due to the stable flow in the pipeline, the internal flow field does not change over time, and the fluid properties do not change over time. Therefore, the water quality inside the pipeline remains constant, meaning that the flow rate is equal at all points. It can be expressed as: where A

1 and A2 are the cross-sectional areas of the pipeline at points 1 and 2, respectively, and v

1 and v2 are the flow velocities at points 1 and 2, respectively. Calculation of flow velocity and pressure difference: By simplifying and deriving the Bernoulli equation, the relationship between flow velocity v1 and pressure difference Δ p can be obtained. The specific process is as follows: Divide both sides of the Bernoulli equation by ρ g and simplify to obtain the expression for the flow velocity v1. Using the flow continuity equation, represent v2 as a function of v1. Substitute the expression of v2 into the simplified Bernoulli equation and solve for the relationship between v1 and the pres
