Fisher Flow Meter Gas Regulators: Integrated Flow Measurement for Natural Gas Distribution
Quick Answer: Fisher gas regulators keep outlet pressure stable on natural gas distribution lines. They are pressure devices, not flow meters. You need a separate flow meter such as a vortex, thermal mass, or ultrasonic gas flow meter at the regulator station. Silver Automation Instruments supplies natural gas flow meters with 4-20 mA HART, Modbus RTU, and pulse outputs for these stations.
Fisher gas regulators appear on many natural gas distribution skids. They reduce high inlet pressure to a stable downstream pressure for burners, generators, and local networks. Together, the regulator and flow meter create an integrated flow measurement point for natural gas distribution. A common setup in Southeast Asia and Africa uses a Fisher 627 or similar regulator on a 2 inch line. The pressure drops from 6 bar to 0.8 bar. The operator knows the downstream pressure. The operator does not know the actual gas flow.
This gap matters for billing, leakage monitoring, and burner control. Pressure control and flow measurement are two different functions. The regulator position is not a reliable flow signal. A partially open valve can pass different flow rates at different upstream pressures and downstream demands. Most engineers skip this point until a gas bill or a process upset forces the issue. We have seen this on customer sites many times.
Why Add a Flow Meter to a Fisher Regulator Station
You add a flow meter because natural gas flow data supports daily operations. Distribution operators need Nm3/h or kg/h for billing and for tracking consumption. Maintenance teams use flow trends to spot leakage or oversized burners. A flow meter also helps balance supply across multiple branch lines.
At a regulator station, the meter usually sits downstream of the regulator. Because the downstream pressure is stable, the meter reads a more consistent gas density. Some sites install the meter upstream of the regulator. That works if the upstream pressure stays within the meter range and the gas is clean.
In practice, most customers ask for a meter with 4-20 mA HART output. That signal feeds a PLC or RTU. Some also add Modbus RTU for local display or data logging.
Gas Flow Meter Options for Natural Gas Distribution
Vortex flow meters work well on DN25 to DN200 gas lines. They handle line pressures up to 40 bar and temperatures up to 250°C. They output 4-20 mA HART and can include a local display. Vortex meters need straight run. Allow 15D upstream and 5D downstream. For a 2 inch line, that means about 760 mm upstream straight pipe.
Thermal mass flow meters suit low flow and flare gas. They give direct mass flow in kg/h. They do not need external temperature and pressure compensation. Install one when the gas flow range is wide or when the pipe size is small. They respond well at low velocity.
Ultrasonic flow meters fit larger distribution lines from DN50 to DN300. They create almost no pressure drop. They work for custody transfer when paired with pressure and temperature transmitters. Silver Automation Instruments supplies clamp-on and inline ultrasonic meters for gas.
Coriolis mass flow meters are also an option when accuracy is critical. They measure mass flow directly and h
Installation Details That Matter
Send us these data before ordering a gas flow meter: pipe size DN, gas type, minimum and maximum flow rate, inlet pressure, outlet pressure, gas temperature, and hazardous area requirement. Natural gas stations often need ATEX Zone 1 or Zone 2 certification. Silver can supply Ex d or Ex ia transmitters and flow meters.
One customer site in Vietnam used a Fisher 627 regulator on a 2 inch natural gas line. Inlet pressure was 6 bar. Outlet pressure was 0.8 bar. The line fed a small industrial park. They needed total flow for monthly billing. We supplied a DN50 vortex flow meter with an integrated PT100 and pressure sensor. The output was 4-20 mA HART to an RTU. The meter paid for itself in about four months because billing disputes dropped.
For gas temperature compensation, install a PT100 downstream of the flow meter. For pressure compensation, install a pressure transmitter near the meter. Most natural gas distribution systems require standard volume flow. You cannot get accurate standard volume from a volumetric meter without pressure and temperature correction.
Silver Automation Instruments and Natural Gas Flow Meter Supply
Silver Automation Instruments is a flow meter manufacturer based in China. We ship gas flow meters to Southeast Asia, Oceania, Latin America, Africa, and the Middle East. We work with contractors and end users in oil and gas, power, food and beverage, and water treatment.
We do not ask for a long vendor registration form before quoting. You send the operating data. We return a data sheet and price. If you need help selecting between vortex, thermal mass, and ultrasonic, tell us the flow range and pipe size. We will recommend a meter that fits your Fisher regulator station. More product details are available at flow-meter.com.au.
FAQ
Question: Can a Fisher gas regulator measure flow by itself?
Answer: No. A Fisher gas regulator controls downstream pressure. It does not give a flow rate output. You need a separate flow meter.
Question: Which flow meter is best for natural gas distribution?
Answer: A vortex flow meter is common for DN25 to DN200 gas lines. Thermal mass is better for low flow or wide turndown. Ultrasonic works well for larger lines from DN50 to DN300.
Question: Do I need temperature and pressure compensation?
Answer: Yes if you use a volumetric meter and need flow in Nm3/h or standard volume. Direct mass meters like thermal mass and Coriolis do not need external compensation.
Question: What output signals do Silver gas flow meters support?
Answer: The standard output is 4-20 mA HART. We also offer Modbus RTU, RS485, and pulse outputs for totalization and remote monitoring.
Question: How do I get a gas flow meter price quote?
Answer: Send pipe size DN, gas type, flow range in kg/h or Nm3/h, pressure in bar, temperature in °C, and hazardous area zone. Contact Tel: +86-25-68650347 or WhatsApp: +86-25-52155837.
For a natural gas flow meter quote, send your pressure in bar, temperature in °C, pipe size DN, and flow range. The Silver Instruments team also answers WeChat at +86 15365082610.
