1. Selection of Annubar for Annubar

Guide for Annubar Flow Meter Brief Installation Guide Step 1: Determine the correct installation direction and straight pipe section requirements for Annubar Flow Meter (DECAnnubar) Step 2: Drill holes on the pipeline Note: Drilling holes must be drilled on the pipeline. If acetylene gas or other ablation methods are used for drilling, the maximum flow error after installation can reach 10%!!! Sensor size, drilling size, drilling error Sensor 119 mm+1 mm / -0.00 mmSensor 234 mm+1 mm / -0.00 mmSensor 364 mm+1 mm / -0.00 mm1. Release the pipeline pressure and discharge the accumulated liquid Choose the location where you will drill holes. For vertical pipelines, you can drill holes at any position in the circumferential direction For horizontal pipelines, the location of openings is based on the application of Annubar fluid measurement ·Measurement of liquids: Hole at the bottom of the pipeline · Measurement of gases: Hole at the top of the pipeline · Measurement of steam: Hole at the bottom of the pipeline 3 Based on the above table, determine the size of the opening four After opening the hole, remove the burrs inside the hole If it is also necessary to install a counter support, drill a second hole in the direction opposite to the first opening, and then remove the burrs inside the hole Step 3: Weld the welding connector onto the pipeline Assemble the welding connectors provided by the factory and insert them into the drilled holes Align the wires on the installation head of the Anuba (or transmitter - if it is an integrated instrument) so that they are parallel to the pipeline Spot welding, fix the welding connection to the pipeline, and then remove the Annubar sensor. 4

Before welding, to prevent welding slag from splashing and damaging the threads of the connecting parts, wrap the threaded part with thick aluminum foil provided by the factory Or tighten a protective nut Uniform welding to prevent deformation of the welded parts and complete the welding Step 4: Insert and install the Annubar flowmeter 1 After the installation connector is completely cooled down, install the connector body. 2 Insert the first sealing ring (packing) between the sealing clamping ring and the pre welded locking ring; Be careful not to damage the sealing ring. 3 Press the sealing ring into the interior of the connecting body to the pre welded locking ring Repeat the above steps to install the remaining two sealing rings, adjust the position of the sealing ring openings so that each opening is staggered at a 180 degree angle Adjust the direction of the Anuba, point the arrow key on the head of the Anuba towards the fluid direction of the pipeline, and tighten the Pak Lok compression nut and connecting body by hand Until the hand cannot twist it. 5 Use a wrench to tighten the Pak Lok nut, evenly tighten the nut, and tighten the nut to a degree that avoids leakage Do not excessively tighten the compression nut, otherwise it may damage the installation components Type spectrum description DEC-ANB throttling device installation form M thread F rough resistant flange body material 1- carbon steel 2- stainless steel 3- high temperature resistant material Measurement pipe diameter 50- DN50 65- 　　DN65 　　　　　　80- 　　DN80 　　　　　　100- 　　DN100 　　　　　　125- 　　DN125 　　　　　　150- 　　DN150 　　　　　　200- 　　DN200 　　　　　　225- 　　DN225 　　　　　　250- 　　DN250 　　　　　　300- 　　DN300 　　　　　　350- 　　DN350 　　　　　　400- 　　DN400 　　　　　　45
