1. Parameters of Anuba flowmeter
1. Specification: DN50-DN5000 (mm); Insertion type: DN500-DN5000
2. Measurement accuracy: ± 0.5%, ± 0.2%; Repeatability: ± 0.1%;
III. Scope: Volume flow rate: 10:1; 100; 1. Quality flow rate: 8:1;
Fourth, working pressure: no lifting function for the averaging tube type: ≤ 29.00MPa;
; Adjustable type of averaging tube: ≤ 10MPa; 5. Fluid temperature: ≤ 450 ℃; 6、 Medium viscosity: ≤ 30CP (equivalent to heavy oil); 7、 Body material: Sensor, three valve group: all made of 316L stainless steel, alloy steel, Hastelloy, Monel and other materials to choose from; Accessory material: Flange: 316L stainless steel or carbon steel, alloy steel, Hastelloy, Monel and other materials can be selected; Introduction to the working principle of KERNB Anuba: When fluid flows through the probe, a high-pressure distribution zone is generated in its front, and the pressure in the high-pressure distribution zone is slightly higher than the static pressure of the pipeline. According to the Bernoulli equation principle, the velocity of the fluid increases as it flows through the probe, creating a low-pressure distribution area at the back of the probe. The pressure in the low-pressure distribution area is slightly lower than the static pressure of the pipeline. After the fluid flows through the probe, a partial vacuum is generated at the rear of the probe, and spiral vortices appear on both sides of the probe. The cross-sectional shape, rough surface condition, and position of the low-pressure tapping hole of the average velocity flow probe are key factors determining the performance of the probe. The stability and accuracy of low-voltage signals play a decisive role in the_600x400.jpg)
1. Measurement of flow rate of various gases, liquids, and steam media
2. Temperature of the measured medium: -60 ℃~850 ℃
3. Pressure of the measured medium: -1.0~42MPa
4. Flow rate of the measured medium: calculated based on the medium
5. Viscosity of the measured medium: calculated based on the medium. The main advantages of the Annubar flowmeter are that it is a new type of differential pressure flow detection element developed based on the pitot tube velocity measurement principle. The sentence is:. The Anuba flowmeter produced by our factory has a novel design, reasonable structure, high accuracy, low pressure loss, and easy installation and use. With its special advantages, it has gradually replaced orifice plates and other detection components in many occasions. The product has passed provincial appraisal. The output of the Anuba flowmeter is a differential pressure signal, which can be used in conjunction with instruments for measuring differential pressure. It can accurately measure various liquids, gases, and vapors (superheated steam and saturated steam) in circular and rectangular pipelines. The size range of the tested pipeline is from 20mm to 3000mm. Anuba has been successfully used in sec
