1. Calculation formula for current carrying capacity of wires and cables
The calculation formula for current carrying capacity of wires and cables is: maximum current carrying capacity=cable cross-sectional area (mm ²) × allowable maximum current density of cable material (A/mm ²).
1. Cable Material and Allowable Maximum Current Density Copper Conductor: The safe current carrying capacity is generally 5~8A/mm ². Aluminum wire: The safe current carrying capacity is generally 3-5 A/mm ². These values are determined based on factors such as the material properties of the wire, the maximum allowable operating temperature, and heat dissipation conditions.
Example of current carrying capacity calculation: Copper wire: 2.5mm ² BVV Copper wire: Safe current carrying capacity=2.5mm ² × 8A/mm ²=20A (recommended value).
. 4mm ² BVV copper wire: safe current carrying capacity=4mm ² × 8A/mm ²=32A (recommended value). Aluminum wire (assuming maximum allowable current density of 4A/mm ²): 2.5mm ² Aluminum wire: Safe current carrying capacity=2.5mm ² × 4A/mm ²=10A. 3. Calculate the cross-sectional area of the wire based on the load current. Using the recommended safe current carrying capacity of the copper wire, the upper and lower range of the required cross-sectional area of the copper wire can be calculated: S=0.125I~0.2I (mm ²) S: cross-sectional area of the copper wire (mm ²) I: load current (A). For example, if the load current is 20A, the required cross-sectional area range of the copper wire is S=0.125 × 20~0.2 × 20=2.5mm ²~4mm ². 4. Power calculation and current estimation. Resistive load: P=UIP: power (W) U: voltage (V) I: current (A) Inductive load (such as sunlight) Lamp: P=UIcos ф cos ф: Power fa
V. Precautions Voltage type: It is necessary to determine whether it is three-phase power supply (380V) or single-phase power supply (220V), as the calculation method is different. Single phase power supply: current=rated power/voltage (220V). Three phase power supply: current=rated power/(voltage (380V) x 1.732 x power factor). External factors: When calculating the current carrying capacity, external factors such as laying method, environmental conditions, temperature, etc. need to be considered. Finally, the cable current carrying capacity table needs to be consulted to select the appropriate cable. 6、 The image displays a schematic diagram of the cable current carrying capacity, which helps to better understand the concept and calculation method of cable current carrying capacity. In summary, the calculation of current carrying capacity for wires and cables involves multiple factors, including cable material, cross-sectional area, load current, power factor, and external conditions. In practical applications, these factors need to be comprehensively considered to ensure the safe operation of wires and cables.
2. How to calculate the current carrying capacity of a cable?
1. Comparison table of three-phase cable current carrying capacity is as follows:
2. Calculation method of
