Air Flow Volume Meter: Electronic Precision Industrial Gas Flow Totalizers
Quick Answer
Silver Automation Instruments supplies air flow volume meters and electronic precision industrial gas flow totalizers for compressed air, nitrogen, oxygen, biogas, natural gas, and mixed gas service. Typical accuracy is plus or minus 1.0 percent of reading for thermal mass meters and plus or minus 0.5 percent of reading for inline vortex meters on clean gas. Send your gas type, pressure in bar, temperature in °C, pipe size in DN, and required flow range for a model and price quote.
What the Meter Does
An air flow volume meter measures gas flow in real time. The electronic totalizer adds that flow into a totalized volume. This gives plant operators both instantaneous rate and total consumption over a shift, a batch, or a billing cycle.
We have seen this on customer sites many times. A plant manager does not need a laboratory instrument. They need a field device that reads directly in standard cubic meters per hour, normal cubic meters per hour, or kilograms per hour.
Meter Selection for Industrial Gas
Thermal mass flow meters work well for compressed air, nitrogen, and clean dry gas because they respond directly to mass flow. Vortex flow meters fit clean gas and some steam applications. The final choice depends on pipe size, moisture level, pressure, and minimum flow rate.
For compressed air systems from DN80 to DN300, we recommend the Silver insertion thermal mass flow meter. It covers gas velocity from 0.3 to 30 m/s, temperature up to 200 °C, and pressure up to 40 bar. For smaller lines from DN15 to DN80, an inline vortex flow meter works well.
Key Specifications
In practice, the output signal matters more than a large display. Standard units include 4-20 mA HART output. Optional outputs include RS485 Modbus, pulse, and two relay alarms. The local display shows actual flow, standard flow, temperature, pressure, and totalized volume.
Temperature compensation uses a PT100 sensor on thermal mass meters. Most units accept DC 24V power. Some models accept 220V AC. The flow computer stores totalized records even during power loss.
Common Applications
Food and beverage plants in Southeast Asia use these meters on packaging air and pneumatic conveying. Water and wastewater stations measure aeration blower air. Chemical plants track nitrogen bl
A customer in Vietnam asked us to measure compressed air on a dairy line. The meter found a 16 percent leakage rate during weekend idle periods. That one finding paid for the meter in less than four months.
Because compressed air leaks are common, a totalizer quickly shows idle consumption. So the plant manager can compare shifts and find leaks before they become a large loss.
Installation Notes
Most engineers skip this part. But straight run matters. For a vortex meter, keep 15D straight pipe upstream and 5D downstream. For a thermal insertion meter, keep 10D upstream and 5D downstream when possible.
Mount the thermal probe at the pipe center line. Do not install the meter directly after a pressure regulator or an elbow. If the gas is wet, install a moisture separator upstream.
How to Get a Quote
Do not send a general inquiry. Send us your gas type, pressure in bar, temperature in °C, pipe size in DN, and required flow range. We will return a model selection, accuracy statement, and price within one business day.
Contact Silver Automation Instruments. Tel: +86-25-68650347. Whatsapp: +86-25-52155837. WeChat: +86 15365082610. Website: flow-meter.com.au
FAQ on Air Flow Volume Meters and Gas Totalizers
Can the meter display mass flow and totalized volume at the same time?
Yes. The totalizer stores both real time flow and accumulated flow. Most units show standard cubic meters per hour and total standard cubic meters.
Which meter works for wet or dirty biogas?
A thermal mass flow meter can handle some moisture but not liquid slugs. For saturated or dirty gas, use a vortex meter or install a flow conditioner and moisture separator upstream.
What output signals are available?
Standard output is 4-20 mA HART. Pulse, RS485 Modbus, and two relay alarms are optional. These signals work with most PLC and SCADA systems.
What is the minimum straight run requirement?
For an inline vortex meter, allow 15D straight pipe upstream and 5D downstream. For insertion thermal meters, 10D upstream and 5D downstream is enough in most installations.
Do you supply for small compressed air lines?
Yes. We offer inline gas flow meters from DN15. For small lines, we check pressure, temperature, and flow range to avoid under sizing.
