1. Yangpai Technology Optical Quantum Gas Liquid Two Phase Measurement SPMF-W
Yangpai Technology Optical Quantum Gas Liquid Two Phase Measurement SPMF-W Yangpai Science and Technology Piso Technology Optical Quantum Gas Liquid Two Phase Measurement SPMF-W is a high-precision flow measurement product based on the throttling principle of the Venturi choke and the optical quantum phase measurement technology. It can accurately measure the total flow rate of the medium and monitor the flow rates of gas and liquid simultaneously, thus enabling accurate analysis of various fluid components in the medium.
1. Product features: High precision measurement: The system design combines light quantum phase separation measurement technology with a Venturi tube, which can independently complete online non separation measurement of oil and gas mixed flow, ensuring the accuracy of measurement results.
. Wide applicability: Its applicability is wider than that of ordinary wet gas flow meters, with LVF (liquid volume fraction) reaching over 95%, suitable for real-time monitoring and control of gas-liquid two-phase flow in various media. Multiple data transmission methods: Provides RJ45, RS485, 4G and other data transmission methods to meet the data transmission needs of different venues, ensuring real-time and reliable data. Powerful System Processing Software: Equipped with powerful system processing software, it supports remote, automated, and fast completion of system operations and data analysis, improving work efficiency and accuracy. Small size, low energy consumption: The product is designed to be small in size, low in energy consumption, easy to install, safe to operate, and suitable for various tedious e
2. Performance Index Product Description: Suitable for production measurement at oil/gas well wellheads, meeting the flow measurement needs of various oil and gas wells.
. Specification and Size: We offer various sizes ranging from DN25 to DN50, which can be selected according to actual needs. Design pressure: ≤ 32MPa, ensuring the stability and safety of the product in high-pressure environments. Medium temperature: -40 ℃/100 ℃, suitable for flow measurement under various temperature conditions. Environmental temperature: -40 ℃~+85 ℃, ensuring the normal operation of the product in various extreme environments. Environmental humidity: (0~95)% RH, suitable for various humidity environments, ensuring the stability and reliability of the product. Explosion proof rating: Ex db IIB T4 Gb, meeting explosion-proof requirements and ensuring safety in flammable and explosive environments. Protection level: IP66, with good waterproof and dustproof performance, suitable for various harsh environments. Installation method: Vertical installation to ensure measurement accuracy and stability. Mass flow rate (gas, liquid): ± 3.5% to ensure the accuracy of measurement results. Flow range: Refer to the "Bridge Reference Table for Flow Range of Multiphase Flow Meter", and choose according to actual needs. Throttle device: Venturi type, ensuring high accuracy and stabi
