1. Working principle of orifice flowmeter
An orifice flowmeter is a device that calculates gas flow by measuring pressure difference. Its core principle is based on energy conservation and flow continuity in fluid mechanics. Here is a detailed explanation:
1. Working principle: When gas flows through an orifice plate, due to the sudden reduction in the cross-sectional area of the orifice plate, the gas flow velocity increases significantly at the orifice, while the pressure decreases. According to the Bernoulli equation, the kinetic energy and static pressure energy of a fluid are converted into each other, and an increase in flow velocity leads to a decrease in static pressure, thereby forming a pressure difference (Δ P) between the upstream (high-pressure side) and downstream (low-pressure side) of the orifice plate. The relationship between flow rate and pressure difference: Under stable flow conditions, the gas flow rate (qv) is proportional to the square root of the pressure difference (Δ P), that is: qv: gas volume flow rate (m3/min) K: orifice plate coefficient (determined by orifice plate geometry, gas properties, etc., calibrated at the factory) Δ h: water column pressure difference measured by U-tube (mm), multiplied by density ratio 13.6 if using mercury column. By measuring the pressure difference Δ h and combining it with the known K value, the gas flow rate can be calculated.
2. Structure Composition: The orifice flowmeter consists of the following core components: orifice plate: a circular thin plate with a precisely sized circular hole in the center, which is a key component for generating pressure difference.
. Pressure nozzle: located upstream and downstream of the orifice pla
III. Specifications and Selection of Orifice Plate Diameter Selection: The size of the orifice plate is determined based on the estimated gas drainage volume and the range of water column pressure difference Δ h, and is enclosed (usually 100-1000Pa).
. Differential pressure measurement range: Δ h should be within the instrument range to avoid measurement errors caused by being too large or too small. 4. Installation and Use Requirements Concentricity and Verticality: The orifice of the orifice plate must be concentric with the pipeline, the end face must be perpendicular to the axis, and the eccentricity should be ≤ 1%~2%, otherwise it will cause flow disorder and affect the accuracy of pressure difference. Smooth inner wall of pipeline: There are no bumps, welds or gaskets within the 2D range (D is the diameter of the pipeline) before and after the orifice plate, reducing local resistance. Length of straight pipe section: Upstream (front end): A straight pipe section of 20D is required to ensure stable gas flow. Downstream (rear end): A straight pipe section of 10D is required for bending to avoid vortex interference. Maintenance and cleaning: Regularly clean the accumulated water and dirt before and after the orifice plate, and replace the orifice plate when it is severely corroded. Dynamic adjustment: When the gas flow rate changes significantly, the
